Multifunctional rehabilitation training system
UniGym All-in-One Home Gym System
The manufacturer describes UniGym as a multifunctional rehabilitation robot covering hand, upper-limb and lower-limb training in a single portable device, used with a companion app.
Official videos
Written summary (EN / ES)
English
- Presents UniGym as a single portable main unit for hand, upper-limb and lower-limb training.
- Shows the device mounted on a flat surface with its suction-cup base and used from a seated position.
- Shows the companion mobile app used to select training and follow session activity.
Español
- Presenta UniGym como una única unidad principal portátil para entrenamiento de mano, miembro superior y miembro inferior.
- Muestra el dispositivo fijado sobre una superficie plana con su base de ventosa y utilizado desde una posición sentada.
- Muestra la aplicación móvil complementaria usada para seleccionar el entrenamiento y seguir la actividad de la sesión.
Accessibility summary prepared by AOR from the official manufacturer video. Not a verbatim transcript, clinical claim or regulatory statement.
Written summary (EN / ES)
English
- Shows the interchangeable modules: rotation module, pull-rope module and pneumatic rehabilitation glove.
- Illustrates how modules attach to the same main unit to change the type of training.
- Highlights the compact, portable format for home or clinic use.
Español
- Muestra los módulos intercambiables: módulo de rotación, módulo de cuerda de tracción y guante neumático de rehabilitación.
- Ilustra cómo los módulos se acoplan a la misma unidad principal para cambiar el tipo de entrenamiento.
- Destaca el formato compacto y portátil para uso en el hogar o en la clínica.
Accessibility summary prepared by AOR from the official manufacturer video. Not a verbatim transcript, clinical claim or regulatory statement.
Official YouTube videos
Written summary (EN / ES)
English
- Introduces the device and the training scenarios the manufacturer positions it for.
- Walks through the main unit, the modules and how a session is set up.
- Describes intended users in general terms, without stating a clinical indication.
Español
- Introduce el dispositivo y los escenarios de entrenamiento para los que el fabricante lo posiciona.
- Recorre la unidad principal, los módulos y cómo se configura una sesión.
- Describe a los usuarios previstos en términos generales, sin declarar una indicación clínica.
Accessibility summary prepared by AOR from the official manufacturer video. Not a verbatim transcript, clinical claim or regulatory statement.
Written summary (EN / ES)
English
- Step-by-step tour of the companion app: pairing the device and starting a session.
- Shows selecting a training mode and adjusting resistance or range settings.
- Shows how session activity is displayed after training.
Español
- Recorrido paso a paso de la app complementaria: emparejar el dispositivo e iniciar una sesión.
- Muestra cómo seleccionar un modo de entrenamiento y ajustar la resistencia o el rango.
- Muestra cómo se presenta la actividad de la sesión después del entrenamiento.
Accessibility summary prepared by AOR from the official manufacturer video. Not a verbatim transcript, clinical claim or regulatory statement.
Written summary (EN / ES)
English
- Teaching demonstration of a seated knee-flexion exercise performed with the device.
- Shows positioning, attachment of the module and the movement pattern.
- Educational demonstration only; exercise selection is decided by a qualified clinician.
Español
- Demostración didáctica de un ejercicio de flexión de rodilla sentado realizado con el dispositivo.
- Muestra la colocación, el acople del módulo y el patrón de movimiento.
- Demostración educativa únicamente; la selección de ejercicios la decide un clínico calificado.
Accessibility summary prepared by AOR from the official manufacturer video. Not a verbatim transcript, clinical claim or regulatory statement.
Written summary (EN / ES)
English
- Teaching demonstration of a seated shoulder-abduction exercise performed with the device.
- Shows seated setup, module attachment and the guided movement.
- Educational demonstration only; exercise selection is decided by a qualified clinician.
Español
- Demostración didáctica de un ejercicio de abducción de hombro sentado realizado con el dispositivo.
- Muestra la preparación sentado, el acople del módulo y el movimiento guiado.
- Demostración educativa únicamente; la selección de ejercicios la decide un clínico calificado.
Accessibility summary prepared by AOR from the official manufacturer video. Not a verbatim transcript, clinical claim or regulatory statement.
Manufacturer-stated functions
- Hand, upper-limb and lower-limb training with one main unit
- Interchangeable modules: rotation module, pull-rope module and pneumatic rehabilitation glove
- Accessories: foot pedals, pull-rope handle, ankle strap, forearm handle and arm-cycling handles
- Mounts on floor, tabletop or door via suction-cup fixation
- Wireless battery operation with iOS/Android app control
- Manufacturer states NMPA (China) registration is in progress for the medical configuration
Detailed function breakdown
Hand rehabilitation
- Pneumatic rehabilitation glove drives finger flexion and extension cycles
- Passive, assisted and active training modes selected from the app
- Grip and release training with adjustable cycle timing
- Mirror-style bilateral hand practice with the unaffected side
Upper-limb training
- Arm cycling with the rotation module and arm-cycling handles
- Shoulder and elbow range-of-motion cycles at 0–60 rpm
- Resisted pull-rope work from 2 to 10 kg for strength progression
- Forearm handle for pronation and supination patterns
Lower-limb training
- Seated pedal cycling for hip, knee and ankle mobilization
- Ankle strap for lower-limb pull-rope resistance work
- Adjustable rotational torque from 0 to 6 Nm
Setup and mounting
- Suction-cup fixation on floor, tabletop or door (20 kg lateral / 45 kg longitudinal hold)
- Single 6 kg portable main unit with interchangeable modules
- Cordless operation on a 6400 mAh lithium battery
App and program management
- iOS and Android app controls mode, speed, resistance and session duration
- Session tracking for home programs supervised by a therapist
Published specifications
| Dimensions | 27 cm (H) × 49 cm (W) × 22 cm (L) |
|---|---|
| Battery capacity | 6400 mAh lithium |
| Charging voltage | 110–220 V AC |
| Suction cup diameter | 14.7 cm |
| Pull rope length | 0–140 cm |
| Rotation diameter | 17.8 cm |
| Rotational speed | 0–60 rpm |
| Weight | 6 kg (13.2 lbs) |
| Suction cup holding force | 20 kg lateral / 45 kg longitudinal |
| Pull rope resistance | 2–10 kg |
| Rotational torque | 0–6 Nm |
| App OS | iOS / Android |
- Last verified
- 2026-08-01
- Content status
- Official manufacturer content verified — regulatory status not published
